คำอธิบาย

• Analog video-input 16CH inputs
• IP Video Input 4ch,(only IP up to 20ch)
• Composite Video Input up to 20ch (Analog video + IP video)
• Compression Audio: G.711a Video: H.264 / H.265
• Playback 5MP-lite: 96fps (Max 8CH playback) 4MP-lite: 128fps (Max 8CH playback) 1080P: 120fps (Max 8CH playback) 720P:240fps (Max 8CH playback)
• Ethernet 1 RJ45 100/1000 Base-T
• USB2.0*1(front), USB3.0*1+(rear)
• Audio 4 in / 1 out
• HDD 1 SATA HDD, Up to 10 TB capacity
• RS485 1
• Input Voltage/Current DC12V/5A
